I hope you have found this article worth reading. There is a more complicated trick for switch tool palette folders, but that involves macros, so we will have to address that in a later post. So, to get other user’s to be able to view the new palette, right-click on the palette bar, select All palettes.Īnd then they can select the palette to use: What I mean by transferrable is that even though you create a group for a palette, the other users aren’t able to share that group. One of the downsides of tool palettes is that groups aren’t transferrable. Learn about the basics of creating tools and adding them to palettes, organizing and naming the tools, saving and distributing palettes from a network. For everyone from new CAD users to advanced CAD users, this session will help speed up efficiency and organize tools for team use.

#HOW TO ADD A TOOL TO THE TOOL PALETTE IN AUTOCAD 2017 HOW TO#

However, put the network folder below the user folder, so they create their own palettes on their own computer. Learn how to create, standardize, and distribute tool palettes within a company network and/or organization. The procedure is the same as we used to add the path to our profile. To allow others to use our tool palettes, we need to add the network path to their profile.

While we have put the tool palettes up on the network, added our content, and set the permissions to read-only, other users still can’t access them from AutoCAD. The nice thing about read-only palettes is that the user can tell which palette is read-only by a little lock symbol. I’d use this if you are more concerned about preventing accidental edits than user access. This method is less secure, since anyone with permission can uncheck the read-only box. Tool palettes checklist Set up a mapped drive on the network Create folders. Because deny permissions take precedence, users will be able to read the files, but not write or change them.Ī simpler method would be to right-click on the folder, select properties and check the read-only box. (click image to enlarge) Click on the OK button to close the dialogue and save your Macro. You can now paste your Macro in under ‘Command string’.

Any non-admin CAD user should be a member of the CAD user group. To add your command Macro to the new toolbar button, right click on the ‘Run script’ tool palette button, and chose ‘Properties’. If you have IT people or are familiar with folder permissions, create a cad user group and deny write privileges to the tool palette folder. Making the folder read-only can be accomplished in a couple ways. To prevent unauthorized access, make the folder containing the tool palettes read-only to non-admin users. Make sure that the palette you want the symbol on is current.īecause tool palettes can represent a tremendous amount of work, they should be protected from the general users. To add P&ID content, open your project setup, navigate to the symbol you want to add, and click Add to Tool palette. As long as user’s use the tool palette, the layer will get created and the color will be set as needed. Drag drawings, blocks, and hatches from DesignCenter. You can also add lights, cameras, visual styles, and materials (not available in AutoCAD LT). Tools include geometric objects, dimensions, fills, blocks, xrefs, raster images, and tables. If you add it to your acad.lsp file it will add another duplicate line to the setting every time your acad.lsp runs. You can add tools to a new or existing tool palette using several methods. I’ve create a new palette named ACME which will allows users to draw items on the ACME layer. You only need to run this once as the file paths are stored in the registry.

A new tool palette with the folder or DWG name that you right-clicked on is automatically created and, like magic, it includes tools for all the blocks Now you have quick and easy access to your favorite blocks. Choose Create Tool Palette from the right-click menu. So here’s what the changes look like on my computer.īecause AutoCAD uses the top path as the editing directory, any changes we make will be saved to the network location. Right-click on the folder or DWG file that contains your block definitions. The first we will do is modify our options to include the path to the network at the top entry. Now that we have our palettes accessible, we need to modify them to include necessary content. If you cannot see the AppData folder, go to Organize > Folder and search options > View and Enable Show hidden files, folders, and drives.Ĭopy the files in the folder, and paste them at your preferred network location.

#HOW TO ADD A TOOL TO THE TOOL PALETTE IN AUTOCAD 2017 WINDOWS#

Open the folder at the specified path in Windows explorer. Go to Options > Files > Tool Palette File Locations. Tool palette locations are defined in the AutoCAD profile.
